Artesyn Embedded Power, part of Advanced Energy, is a global leader in the design and manufacture of AC-DC power supplies and DC-DC converters. With decades of experience and engineering excellence, Artesyn products are renowned for their outstanding performance, reliability, and cost-effectiveness — delivering dependable power to critical systems across a wide range of industries.
EXTENSIVE PORTFOLIO OF POWER SOLUTIONS
Our product range is one of the most comprehensive in the market, covering both AC-DC and DC-DC conversion technologies:
-
AC-DC Power Supplies:
Power ratings from 3 watts to 960 watts for low- and medium-power applications, and up to 24,000 watts for high-power systems. -
DC-DC Converters:
A broad selection of isolated converter modules, including quarter-brick, half-brick, and full-brick designs, engineered for efficiency, thermal stability, and versatility. -
Power Factor Correction (PFC) Modules:
Complementary solutions that enhance energy efficiency and system performance.
Each Artesyn product is built to meet the highest international standards, ensuring long-term reliability and seamless integration into complex systems.
TAILORED SOLUTIONS FOR SPECIALTY MARKETS
In addition to our standard product lines, Artesyn Embedded Power develops application-specific power supplies for specialized industries such as:
-
Avionics and Aerospace
Rail and Transportation
-
Industrial Automation
-
Telecommunications and Data Systems
Our ability to combine custom engineering, advanced power density, and robust design ensures optimal performance even in the most demanding environments.
RELIABILITY, PERFORMANCE, AND VALUE
Artesyn's reputation is built on trust, innovation, and precision.
We continuously invest in research, design, and manufacturing excellence to provide customers with power solutions that deliver measurable value — performance you can rely on, efficiency that drives progress, and flexibility that adapts to your application needs.
PRODUCTS OVERVIEW
CHOOSE FROM OUR PRODUCT CATEGORIES
Description
Datasheet
Power
Input Voltage
Output Voltage
- 4000 Vac reinforced insulation
- Medical safety to UL/cUL/EN/IEC 60601-1 3rd Edition
- 2 MOOP rated
- Wide 2:1 input voltage range
6 W12 V, 24 V or 48 VSingle, Dual- 4200 VAC reinforced insulation
- Insulation rated for 300 Vac working voltage
- Medical safety to UL/CSA/EN/IEC 60601-1 3rd Edition
- 2 MOOP rated
10 W12 V, 24 V or 48 VSingle, Dual- Output voltages from 1 to 20 kV
- Input DC noise rejection filter
- Small footprint and modular design
- Efficient and reliable operation
10 W1 A, max1 to 20 kV- 4200 Vac reinforced insulation
- Insulation rated for 300 Vac working voltage
- Medical safety certifications
- 2 MOOP rated
15 W12 V, 24 V or 48 VSingle, Dual- 4200 Vac reinforced insulation
- Insulation rated for 300 Vac working voltage
- Medical safety certifications
- 2 MOOP rated
20 W12 V, 24 V or 48 VSingle, Dual- Inrush current max. 50 A, 230 VAC input, cold start at 25 °C
- Frequency 47 - 440 Hz
- Safety ground leakage current 275 uA at 50/60 Hz, 264 VAC input
- Efficiency typically 87% at full load
20 W90-264 VAC, 120-300 VDC4.5V to 57.6V- Inrush current max. 50 A, 230 VAC input, cold start at 25 °C
- Efficiency typically 87% at full load
- Frequency 47 - 440 Hz
- Safety ground leakage current 275 uA at 50/60 Hz, 264 VAC input
40 W90 to 264 VAC 127 to 300 VDC4.5V to 57.6V- Frequency 47 - 440 Hz
- Input range 90-264 VAC, 127-300 VDC
- Efficiency typically 87% at full load
- Inrush current max. 50 A, 230 VAC input, cold start at 25 °C
60 W90 - 264 VAC, 127 - 300 VDC4V to 28.8V- 100W continuous power
- High efficiency 91.5%
- 36 to 160 VDC wide-range input
- No minimum load requirement
100 W36 to 160 V4.5 V - 56.7 V- 150W continuous power
- High efficiency 90%
- 36 to 160 VDC wide-range input
- No minimum load requirement
150 W36 to 160 V4.5 V - 59.4 V- Fanless - Conduction cooling for sealed box application (4P suffix)
- Airflow/convection cooling (suffix 7P) IP64 rated
- User selectable remote ON/OFF logic
- Output adjustment: ±10%
250 W90 V to 264 V10.8 V to 55.2 V- 350W peak power
- Inexpensive
- Industrial/Medical Security
- High efficiency 91%
300 W90 V to 264 V9.6 V to 57.6 V- 2 phase design
- Dual or single output configuration possible
- High efficiency up to 96%
- Small size 27.5 mm x 12.8 mm x 13.4 mm (LxWxH)
350 W7.5-14 Vdc0.5 to 5Vdc- 504 W continuous power
- High efficiency: 93% (typical)
- High reliability
- Standard full brick outline
500 W86 V to 264 V10.8 V to 13.2 V- 600W single output with 5VDC standby
- Conduction Cooled / No Fan
- -40 to 85°C baseplate temperature (no derating)
- Industrial/Medical Safety Approvals
600 W90 V to 305 V12 V to 54 V- 600W mass output
- Inexpensive
- Convenient size 2.4 x 4.5 x 7.5
- Industrial/Medical Safety Approvals
600 W90 V to 264 V57.6 V- Dual input backup
- Medical Type BF Ready
- Active power factor correction, 61000-3-2 compliant
- Built-in class B EMI filter
650 W90 V to 264 V12 V to 52.8 V- Delivering up to 25 A output
- Ultra-high efficiency 95.5% typ. at full load
- Wide input range: 36 ~ 75 Vdc
- No minimum load requirement
700 W36 V to 75 V14 V to 33 V- 900 W continuous power
- Ultra high efficiency: 96.7% peak
- 40 - 60 VDC Datacom input range
- Contact cooling or heatsink mounting
900 W40 - 60 Vdc12.25 V- 1000 W output power without derating
- Inexpensive
- Intelligent variable speed fans
- DSP controlled
1,000 W90 V to 264 V10.8 V to 52.8 V- Ultra high efficiency: 97.7% peak
- 40 to 60 VDC telecomm input range
- Base-plate for contact cooling or heatsink mountingo
- Fixed switching frequency
1300 W40 to 60 VDC9.6 to 13.2 V- 1300 W continuous power
- Efficiency: >95.5% peak
- 36 to 75 VDC telecomm input range
- Base-plate for contact cooling or heatsink mounting
1300 W36 to 75 VDC14V to 32.9V- 1500 watt output power without derating
- Inexpensive
- 12 watts per cubic inch
- Industrial/Medical Safety Approvals
1,500 W90 V to 264 V52.8 V- Full medical EN60601 approval
- High power density (8.8 W/cu-in)
- Voltage adjustment on all outputs
- Configurable current limit
Up to 1500 W85 to 264 Vac 120 to 300 VdcUp to 21- 1600 W continuous power
- Ultra high efficiency: 97.7% peak
- 40 to 60 VDC telecomm input range
- Base-plate for contact cooling or heatsink mountingo
1600 W12.25 VSingle- Ultra-high density
- 1U power supply
- Active power factor correction
- EN61000-3-2 harmonic compliance
1800 Watt90 V to 264 V12.2- High power density (13.9 W/cu-in)
- Full medical safety approvals
- Rugged MIL-STD-810E
- Optional conformal coating
Up to 1800 Watts85 to 264 VAC 120 to 300 VDCUp to 12- 2000 W output power
- High power and short form factor
- 1U power supply
- High density design: 62 W/in
2000 W-40 to -72 VDC11.8 V - 12.8 V- 1200 W full power at elevated temperatures
- Wide operating temperature range (-40°C to 85°C baseplate)
- Adjustable output
- Remote output On/Off
2100 W90 to 264 VAC24 V to 30 V- Ultra-high density
- 1U power supply
- Active power factor correction
- EN61000-3-2 Harmonic compliance
2400 W180 to 264 VAC / 180 to 336 VDC-- +/- 25% adjustment range
- Inexpensive
- -40°C to +70°C with derating
- DSP controlled
3,000 W90 V to 264 V2.4 V to 60 V- Highly accurate droop + active current sharing
- Houses 6 x 3000 W power modules and a removable shelf controller
- Very high efficiency
- Accepts 3 types of input configurations (3P Delta 4 W, 3P Wye 5 W, 3 x of 1P)
6 x 3000 W346 to 480 VAC 3 phase 5 wire Wye (3ph + N + E) / 200 to 277 VAC 3 phase 4 wire Delta (3ph + E)50.5 VDC- 3Phase
- Current Share on all outputs greater than 10A
- Field Demonstrated MTBF to 550K Hours
- Industrial Shock/Vib (>50G's)
3120 W85 to 264 VAC 380, 440 VAC 120 to 300 VDC 1-Phase 3-Phase2V to 60V- Ultra-high density
- 1U power supply
- Active power factor correction
- EN61000-3-2 compliant harmonic compensation
3200 W180 V to 264 V12.2- Accepts low and high line AC
- Input frequency 47 - 63 Hz
- Titanium efficiency certified
- 20 ms hold-up time at 100% load
3200 W90 to 132 VAC 180 to 264 VAC1600 W low line 3200 W high line- 5 and 8 slot cases available
- Short circuit protection
- Over voltage protection
- Over temperature protection
4000 W90 V to 264 V300V- Short circuit protection
- Over voltage protection (OVP)
- Over current protection (OCP)
- Over temperature protection (OTP)
4,000 W90 V to 264 V0.5 V to 57.6 V- Wide input voltage range
- High efficiency: up to 95%
- Industrial safety
- Five-year warranty
LCM4000HV:
4000 Watts
LCM12K: 12 kWattsee DatasheetVoltage source:
100 to 300 VDC
Current source: 0 to 16- Outputs in parallel up to 1600 A
- Outputs series up to 1000 V
- 100% digital control
- Outputs programmable as voltage or current source
24,000 W180 V to 660 V0.6 V to 1000 V
Description
Datasheet
Power
Input Voltage
Output Voltage
- Ausgangsspannungen von 1 bis 20 kV
- Eingangs-DC-Rauschunterdrückungsfilter
- Geringe Stellfläche und modulares Design
- Effizienter und zuverlässiger Betrieb
10 W1 A, max1 to 20 kV- 1300 W Dauerleistung
- Wirkungsgrad: >95,5 % Spitze
- Telekommunikations-Eingangsbereich von 36 bis 75 VDC
- Grundplatte für Kontaktkühlung oder Kühlkörpermontage
1300 W36 to 75 VDC14V to 32.9V- 1200 W volle Leistung bei erhöhten Temperaturen
- Großer Betriebstemperaturbereich (-40 °C bis 85 °C Basisplatte)
- Anpassbarer Ausgang
- Fernausgang Ein/Aus
2100 W90 to 264 VAC24 V to 30 V- Großer Eingangsspannungsbereich
- Hohe Effizienz: bis zu 95 %
- Arbeitssicherheit
- Fünf Jahre Garantie
LCM4000HV:
4000 Watts
LCM12K: 12 kWattLCM4000HV: Single Phase: 180 to 264 VA / 311 to 528 VA
LCM12K: Three Phase: 180 to 264 VA / 342 to 528 VA /
540 to 660 VAC
Voltage source:
100 to 300 VDC
Current source: 0 to 16- Großer Eingangsspannungsbereich
- Hoher Wirkungsgrad: bis zu 95 %
- Arbeitssicherheit
- Fünf Jahre Garantie
LCM4000HV:
4000 Watts
LCM12K: 12 kWattsee DatasheetVoltage source:
100 to 300 VDC
Current source: 0 to 16
