Advanced Energy NCF1200
1200 W Medical Power Supply for Demanding Applications
With the NCF1200 Series, Advanced Energy introduces a powerful and compact AC/DC power supply solution specifically designed to meet the demanding requirements of modern medical technology.
The NCF1200 Series delivers up to 1200 W of output power and is available with output voltages of 12 V, 24 V and 48 V. A 15 V version is available upon request. Its compact, enclosed metal housing with an integrated variable-speed fan allows easy integration into applications where installation space is limited.
A key feature is its suitability for medical applications with Type CF requirements according to IEC 60601-1. The power supplies provide reinforced isolation (2 MOPP between input and output), low patient leakage currents and 5 kV defibrillator withstand capability.
Key Technical Features at a Glance
- Output Power: Up to 1200 W
- Output Voltages: 12 V, 24 V, 48 V (15 V upon request)
- Input Voltage: 85–264 VAC
- Efficiency: Typically over 90%
- Patient Leakage Current: Less than 10 µA under normal conditions (input-to-output)
- Medical Safety: IEC 60601-1, Edition 3.2, suitable for Type CF applications
- Cooling: Integrated variable-speed fan
- Operating Temperature: −10°C to +70°C (power derating above +50°C)
- Additional Output: 5 V / 2 A standby
- Protection Features: Overvoltage, overload, short-circuit and overtemperature protection
- Warranty: 3 years
The combination of high power density, advanced medical safety features and a wide input voltage range makes the NCF1200 Series an ideal solution for demanding medical devices and systems.
For further technical information and detailed specifications, please refer to the attached datasheet.
